Use: Municipal pipe network engineering.
Main Parts And Materials
Valve body/valve cover/gate
Valve stem
Middle mouth gasket
Valve stem nut
Gray cast iron, ductile iron
Carbon steel, brass, stainless steel
Xb300
Ductile iron, brass
Function And Specification
WZ545T-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature ≤100℃
Applicable medium Water
WZ545W-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature ≤100℃
Applicable medium Oil
