Application: This valve is widely used in the petroleum, chemical, pharmaceutical, electric power and other industries, and is used for opening and closing on pipelines with steam, water and oil media with a nominal pressure of ≤1.0MPa.
Usage:Tum on or turan off the pipelines where the nominal pressure is≤1.0MPa and the medium must be stem,water or oil,which can be used in fields of petroleum industry,chemical indemical industry，pharmaceutical industry and power industry.
Main Parts and Materials
Valve body/valve cover/gate
Valve stem
Middle mouth gasket
Valve stem nut
Handwheel
Gray cast iron, ductile iron
Brass, stainless steel
PTFE
Brass
Gray cast iron/ductile iron
Function And Specification
A+Z45T-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1
Applicable temperature ≤100°C
Applicable medium Water
A+Z45W-10
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.1
Applicable temperature ≤100°C
Applicable medium Oil products
A+Z45T-16
Nominal pressure 1.6MPa
Test pressure (MPa)
Strength (water) 2.4
Seal (water) 1.76
Applicable temperature ≤100°C
Applicable medium Water
A+Z45W-16
Nominal pressure 1.6MPa
Test pressure (MPa)
Strength (water) 2.4
Seal (water) 1.76
Applicable temperature ≤100°C
Applicable medium Oil products
