Usage: The valve can be used in the medium temperature is not higher than 80℃for river closure on the pipeline and equipment.
Main Parts and Materials
Valve body/valve cover
Valve stem
Gate
Valve stem nut
Handwheel
Ductile iron
Stainless steel
Ductile iron + NBR
Ductile iron, brass
Gray cast iron, ductile iron
Function and Specification
Z85X-10Q
Nominal pressure 1MPa
Test pressure (MPa)
Strength (water) 1.5
Seal (water) 1.1
Applicable temperature 1~80℃
Applicable medium Water
Z85X-16Q
Nominal pressure 1.6MPa
Test pressure (MPa)
Strength (water) 2.4
Seal (water) 1.76
Applicable temperature 1~80℃
Applicable medium Water
